Artikel: 16260.100X -

LORO-X balcony direct vent with VS-collar series HF balcony floors DN 100

LORO-X direct balcony drain, series HF, one-piece, without thermal insulation, vertical outlet, with pre-fitted VS connecting collar made of multi-layer composite material, for sealing with composite sealants, according to DIN EN 1253 with raised quality standard, made of steel, hot-dip galvanized, with long-life coating according to DIN EN ISO 2178 on the basis of a 2-component epoxy combination, colour: red-brown, consisting of drain pot, VS connecting collar, clamping ring, holding fixture for strainer (for installation height 15 - 105 mm), strainer for pipe opening for balcony floors, DN100

LORO-Export price without tax: 271,60 €
EAN-Code: 4038088061480
ETIM Class: EC011398
Nominal diameter: DN 100
Outside measurements (HxWxL): 330 x 330 x mm
Weight: 4,20 Kg (STK)
Product group (WG): 4
Customs tariff number: 73089098
Produktfinder/Serie: Link
Material and Color: Stahlfeuerverzinkt, Silber

Feedback for this article?

Complete System LX978-12X

with

LORO-X direct balcony drain, series HF, one-piece, without thermal insulation, vertical outlet, with pre-fitted VS connecting collar made of multi-layer composite material, for sealing with liquid plastic/composite sealants, according to DIN EN 1253 made of steel, hot-dip galvanized, with long-life coating according to DIN EN ISO 2178 on the basis of a 2-component epoxy combination, colour: red-brown, consisting of drain pot, VS connecting collar, clamping ring, holding fixture for strainer (for installation height 15 - 105 mm), strainer for pipe opening for balcony floors, proof of performance according to specification sheet LX 978, DN 100

Piece list according to Datasheet LX978-12X:

1 x 16260.100X -
1 x 01005.100X - LORO-X PIPE WITH 1 SOCKET 2750 MM DN 100
1 x 00911.100X - LORO-X SEALING ELEMENT SBR DN 100
1 x 00986.000X - LORO-X LUBRICANT 250 G TUBE
