![](/fileadmin/_processed_/8/e/csm_21908.100X_2d29257c28.jpg)
LORO-DRAINLET® DL pipe penetrations, DN 70 - DN 125 | |||
DN 70 | DN 100 | DN 125 | |
a) without thermal insulation | 21908.070X | 21908.100X | 21908.125X |
b) with thermal insulation | 21909.070X | 21909.100X | 21909.125X |
![](/fileadmin/_processed_/c/d/csm_21991.100X_11dfdb4e69.jpg)
Bottom unit Series 84 DN 70 - DN 125 | |||
DN 70 | DN 100 | DN 125 | |
a) without thermal insulation | 21991.070X | 21991.100X | 21991.125X |
b) with thermal insulation | 21992.070X | 21992.100X | 21992.125X |
LORO-X Sliding flanges for vapor barrier height-adjustable bendable
LORO-X VARIOKANT Sliding flanges for bending on site are suitable for a vapor diffusion-tight pipe penetration through the vapor barrier, especially for the drain pipes of the LORO-X parapet drains for the main and emergency drainage.
The bonding flange made of stainless steel can be bended with customary tools so that the height of the pipe penetration can be variably and continuously adapted to the circumstances of the building.
![](/fileadmin/_processed_/2/d/csm_13073.070X_58a598dbfc.jpg)
LORO-X Sliding flange for double pipe for bending on site
DN 40 | DN 50 | DN 70 | DN 100 | |
13073.070X | 13073.100X |
![](/fileadmin/_processed_/a/8/csm_15073.070X_fda99616a7.jpg)
LORO-X Sliding flange for bending on site
DN 40 | DN 50 | DN 70 | DN 100 | |
15073.040X | 15073.050X | 15073.070X | 15073.100X |
![](/fileadmin/_processed_/4/a/csm_13228.070X_b7e3334231.jpg)
LORO-X Sliding flange for LORO-X double pipe parapet direct drains | |||
DN 70 | DN 100 | ||
13228.070X | 13228.100X |
LORO-DRAINLET® Fastening flange made of galvanized steel | ||
DN 70 | DN 100 | DN 125 |
21910.070X | 21910.100X | 21910.125X |
LORO-Balcony drain collar
![](/fileadmin/_processed_/f/6/csm_16800.100X_5fb6485fd0.jpg)
LORO-Balcony drain collar,made of stainless steel, material-no. 1.4301, material thickness 1 mm | |||
DN 050 | DN 070 | DN 100 | |
compatible pipes | 16800.050X | 16800.070X | 16802.100X |
compatible to sockets | 16801.050X | 16801.070X | 16803.100X |
compatible pipes | 16804.050X | 16806.070X | 16810.100X |
compatible to sockets | 16805.050X | 16807.070X | 16811.100X |
LORO-Put off casing cover
![](/fileadmin/_processed_/4/e/csm_18100.100X_705787a1e8.jpg)
LORO-X Put off casing cover | ||
DN 50 | DN 70 | DN 100 |
18100.050X | 18100.070X | 18100.100X |
