Model High-performance spout: LORO.de

LORO-X high-performance spout with power hood

The LORO-X high-performance spout for emergency drainage offers a high discharge capacity with little overflow above the damming element even without a downpipe - i.e. as a real gravity drain.

Compared to simple spout pipes that are guided through the parapet by core drilling, emergency drains already offer a significantly higher drainage capacity. The drainage capacity of conventional emergency drains is even exceeded by this high-performance model, as the overflow edge - via the large round dam element - has a maximum lengthaufweist.

Large scope

Since there is no suction downpipe available to increase the drainage capacity in the case of pure gravity flow, the flow cross-section from the roof surface into the drain is a decisive criterion for the drainage capacity. Because the circumference is particularly large, a small height above this circumference is sufficient to create a large cross-sectional area for the drainage from the roof.

Less Speier

By using the LORO-X high-performance spout, working time and material usage are reduced, as a large number of low-performance spouts are no longer required. In addition, the use of just one high-performance spout has a positive effect on the aesthetics of the building.

Advantages of the high-performance spout.

1 high-performance spout (9.1 l/s) replaces up to 30 conventional spouts (0.3 l/s)
High discharge even as a spout without a downpipe
Low water height above the dam element

LORO-Attikastar^®scupper-emergency drain, DN 100
	DN 100
with 40 mm weir height	01394.100X

LORO-X Silding flanges with pre-installed connection sleeve for vapor barrier made of bituminous or plastic-roofing sheets (please indicate manufacturer and material of the sealing sheet to be attached), made of galvanized steel, including fastening screws
	DN 100
for bituminous roofing sheets	13235.100X
for plastic roofing sheets	13236.100X
